ZENIUS -
Zenius is the one-stop solution to print high-quality single-sided cards, in monochrome or color, and encode technology cards, singly or in runs, for a variety of applications:
Zenius comes with two major innovations :
Zenius makes it easy for you every step of the way! Discover a wealth of advanced features loaded in a contemporary yet compact design.
Equipped with state-of-the-art printing technologies, the Expert version of Zenius can be upgraded onsite with multiple encoders. These flexible features ensure that you will always be in line with your current and future requirements in plastic card printing.
Compact, lightweight and silent:
With a low sound level and its amazingly small size, Zenius can be accommodated in virtually any environment, be it a welcome desk, a sales counter, or an office desk. By its really low weight, Zenius is the lightest printer in its category.
Zenius has earned the coveted ENERGY STAR certification and complies with the reduced energy consumption guidelines from the ErP European Directive
* Expert version and above
Printing performances
Card management and specifications
Evolis High Trust® ribbons®
Maximize the quality and durability of printed cards, the lifespan of your print head and the overall reliability of your printer!
Display
Software
Supplied with the Evolis Premium Suite® for Windows:
Supplied with the eMedia CS Card Designer (30-day free trial to be downloaded from Mediasoft’s website)
Other OS: Mac and Linux: upon request
| Feeder capacity | 50 cards (0.76 mm – 30 mil) |
| Output tray capacity | 20 cards (0.76 mm – 30 mil) |
| Card thickness | 0.25 to 0.76 mm (10 to 30 mil), calibration via the gauge |
| Types of cards | all PVC , Composite PVC, PET, ABS* and special varnish* cards |
| Card format | ISO CR-80 – ISO 7810 (53.98 mm x 85.60 mm – 3.375” x 2.125”) |
| *Under specific conditions | |
| Ribbon capacity: | |
| YMCKO | 100 cards/roll |
| KO | 300 cards/roll |
| Monochrome ribbon | jup to 1,000 cards per roll (Under specific conditions) |
| Hologram ribbon | 400 cards/roll |
| Interfaces | USB 1.1 (compatible 2.0) Ethernet available as an option |
| Size ( H x L x W) | 195 mm (7.68”) x 205 mm (8.07") x 310 mm (12.2”) |
| Weight | 3.3 kg (7.3 lbs) |
| Sound (evaluated according to the ISO 7779 Standard) | |
| Sound pressure level, LpAm, bystander position (YMCKO color mode) | |
| When operating | 46dB (A) |
| In sleep mode | Background noise only |
| Safety | |
| Support for Kensington® lock | |
| Data encryption for magnetic encoding (Available from November 2011 for the ‘Expert’ version or above) | |
| Packaging content | |
|
|
| Options & accessories | |
| Available colors | Fire Red or Grey Brown |
| Ethernet TCP-IP (Available from November 2011 and for the ‘Expert’ version or above) | |
| Encoding options1, than can be combined. Upgrade can be carried out onsite, by adding new modules: | Magnetic stripe encoder, smart card contact station, smart card encoder and contactless smart card encoder. Other encoders available upon request. |
| Eco-friendly design, certifications and statement of compliance | |
1 Expected by September 2011 |
|
| Power | |
| Power supply | 100–240 V AC, 50–60 Hz, 1.8 A |
| Printer | 24 V DC, 3 A |
| Environment | |
| Min/max operating temperature | 15° / 30°C (59° / 86°F) |
| Humidity | 20% to 65% non-condensing |
| Min/max storage temperature | –5° / +70°C (23° / 158°F) |
| Storage humidity | 20 to 70% non-condensing |
| Operating ventilation | Open air |
| Resident fonts | |
| Arial 100, Arial Bold 100 | |
| Bar code | Code 39, code 128, EAN 13, Interleaved 2 of 5 |
Primacy is a high-end printer that is easy-to-use, flexible and fast .
When loaded with the Evolis cutting-edge encoding technologies, Primacy turns into the ideal solution to issue cards.
Primacy supports any requirement in card printing and encoding, in medium to large runs . This is the perfect option to deliver :
A card printer which adapts to your needs
|
The premium retransfer printer for high definition cards
With a 1000 card capacity for its card feeder, hopper and color ribbon, the Quantum is the only printer on the market to offer a total printing autonomy of 1000 cards in full color
Quantum prints your texts, logos, photos and barcodes with an outstanding quality, either on single or dual-sided plastic cards. Magnetic stripes, contact and contactless cards encoding capabilities are also available as an option.
* under specific conditions
Compact and easy to use, Tattoo Rewrite allows you to print and erase the same card up to 500 times!
Pebble is the ideal solution for any type of application that requires single-sided printing of badges:
Pebble is delivered with Windows Vista, XP and 2003 Server drivers. Mac and Linux drivers are available for download from Evolis web site.
Equipped with a USB port and an optional Ethernet port, Pebble is delivered with a USB cable and can be installed in a few minutes. The Windows driver and the setup process have been totally reshaped to improve the user interface. eMedia Card Designer software is delivered standard. From the very first time you use Pebble; you can personalize and print badges in a jiffy.
The Pebble range of printers proudly carries the stamp of Evolis’ strong commitment to reliability, and therefore, benefits from unmatched quality along with a pioneering 1-year warranty.
*Under specific conditions
Dualys is the ideal solution for any type of application that requires dual-sided printing of badges:
Dualys is delivered with Windows Vista, XP and 2003 Server drivers. Mac and Linux drivers are available for download from Evolis web site.
Equipped with a USB port and an optional Ethernet port, Dualys is delivered with a USB cable and can be installed in a few minutes. The Windows driver and the setup process have been totally reshaped to improve the user interface. eMedia Card Designer software is delivered standard. From the very first time you use Dualys, you can personalize and print badges in a jiffy.
The Dualys range of printers proudly carries the stamp of Evolis’ strong commitment to reliability, and therefore, benefits from unmatched quality along with a pioneering 1-year warranty. Read more
1 Ever Lasting Reliability
The PEB3LE is based on the same proven concepts and technologies as the Evolis Printer Range.
Thanks to a combination of mechanical, electronic and Firmware improvements, the PEB3LE achieves an unmatched printing quality and produces in afew seconds natural colors and images with an exceptional finish.few seconds natural colors and images with an exceptional finish.
Printing and/or encoding jobs are never lost in case of error: the recovery system automatically resends pending jobs.
2 Powerful
Its modern and esthetic curves hide an ultra-robust and powerful product.
o With a 150 cards/hour print speed in color and a 1000 cards/hour in monochrome, the PEB3LE has the most outstanding throughput of its category.
o Thanks to its ergonomic concepts and its automatic integrated cooling system, the PEB3LE replies to all your needs, from small series card production to large volumes.
3 Ergonomic
The PEB3LE has a clamshell opening that allows easy and fast access to all the printer functions: ribbon installation, cleaning, card thickness.
The detachable card feeder, also available as a printer accessory, allows you to stock several feeders with different card backgrounds and/or thicknesses, according to your needs, or simply to avoid stopping production by changing an empty feeder for a full one.
And for even more interactivity, the Windows driver is supplied with a « monitor port » function which informs the user via the computer that an intervention on the printer is needed (card feeder empty, end of ribbon, printer cleaning, etc.).
4 Flexible
To reply to all market demands in terms of access control and security, in addition to printing standard bar codes, the PEB3LE gives you the possibility to encode magnetic stripe cards and to personalise contact or contact-less chip cards. These options can also be combined on the same printer to reply to certain specific applications.
As your card printing needs of today are not necessarily the same as those of tomorrow, the PEB3LE printer provides an upgradeable mag encoding.
5 Design
Its Hi-Tech design, compactness and choice of three colors of the cover (Lagoon, Ruby or Glacier) allow the PEB3LE to be integrated in any reception or office desk.
6 A turnkey solution
eMedia Card Designer software is delivered standard with every printer. From the first time you use it you personalise and print your own badges easily and without delay.
The PEB3LE is compatible with any software as it is delivered with drivers for Windows 95, 98, NT 4.0, 2000 and Xp as well as driver for Mac OS X.
The standard USB and parallel Centronics ports make the printer plug-and-play. And to make life even simpler, we have included all the cables in the packaging.
7 Economical
The PEB3LE is equipped with the Evolis Ribbon Saver for monochrome printing. With this system, you only use the ribbon length that corresponds to the length of the image to be printed. This print characteristic allows you to double and even triple the capacity of your monochrome ribbons… and to reduce the cost of each card!
Evolis offers a Half-Panel Color Ribbon range, 42% cheaper than the standard color ribbons for all your card printing with ID pictures.
From simple ID cards to fraud-proof security:
A protection film is applied over the surface with hot roller technology, after the graphical and electrical personalization process. The film is either a continuous layer of varnish or a patch. Editing and encoding a secure badge is just a matter of a single pass.
In a few seconds, Tattoo personalizes in monochrome or colour your pre-printed or blank plastic cards. With a 300 dpi standard resolution and ‘near-to-edge’ printing, Tattoo prints pictures, texts, barcodes and logos as required.
Tattoo fully addresses the specific needs of small organizations that print badges in low volume or just once in a while: sport clubs, SMEs, retail outlets, schools, libraries and local authorities. It is ideal for membership cards, subscription and loyalty cards, badges for visitors and employees and much more. Go badge, print yourself!
the advantages of the Tattoo card printer COMPACT The Tattoo is the most compact card printer of the Market! With a footprint of an A4 page, it owes its extreme compactness to the completely new Lift Card System which allows the card to pass on two horizontal levels within the machine. An Evolis innovation! ERGONOMIC Thanks to its novative clamshell opening system, operating a plastic card printer has never been so simple - Installation of the ribbon in one shot thanks to the exclusive integrated core system - Quick and easy maintenance of the cleaning rollers - And if needed, the print head can be replaced in a snap with no tools nor additional adjusments POWERFUL CARD LOADING - A revolutionary solution analyses the thickness of the cards present in the feeder: each time you load the card feeder into the Tattoo, the printer immediately adjusts the thickness and memorises it for the appropriate operation. - The exclusive weight concept of the card feeder applies permanent pressure on the whole card surface and this whatever number of cards loaded in the feeder. - The card feeder is also a detachable feature allowing several series of cards to be prepared at the same time, for example with different designs or different card thicknesses, according to your needs. - Completely enclosed, the card feeder is dust proof and thus guarantees an optimal card printing quality. ERGONOMIC - The Tattoo offers a double operating mode simultaneously: Card by card manual feeding from the front mouth and automatic feeding with the feeder for 100 cards from the back. - The Tattoo integrates a Ribbon Saver feature: you only use the ribbon length you need for the image to be printed; hence reducing your cost/card! ECONOMIC Its price positioning and its low cost per card make the Tattoo the most cost effective monochrome card printer on the Market !
